Converter

LGA-Top-238 ZIF-CS

  • top board of LGA converters
  • ZIF socket accepts many variations of LGA packages, that differ in body thickness.
  • The picture at Accepted package(s) section shows the range of all dimensions of LGA packages, which are accepted by this BGA-Top board.
  • operation (mechanical) life of ZIF socket - 500.000 actuations
  • socket: ZIF LGA52, ClamShell type
  • bottom: 8+3 rows, 8x25+3x20 pins, square, 0.6x0.6mm
  • Order no.: 70-519
  • Price: €

Converter manual

  • For work with LGA device it is necessary put together LGA-Top-238 ZIF with some LGA-Bottom-x board according to the information provided by PG4UW software.
  • Do not directly touch the pins of the converter, because dirt may cause errors during programming of device.
  • For handling with the device we recommended to use a vacuum pipette pick up tool.
  • The picture show, how to put together the LGA-Top-x ZIF-CS and LGA-Bottom-x boards to have complete LGA converter



Accepted package(s)

BGA package



NAME

SYMBOL MIN NOM MAX

Profile

A - - 0.65

Ball Height

A1

Ball Thickness

A2 - - -

Ball Diameter

b 0.65 - 1.5

Body Size

D 17.9 18 18.1

Body Size

E 13.9 14 14.1

Ball Pitch

e - - -

Ball Array D

GD - - -

Ball Array E

GE - - -
